מסוע למכונת קנטים
LOOPTEQ O-600
Stacking unit and return conveyor combined in one machine. The high automation degree makes the LOOPTEQ O-600 a real multi-talent. Finished workpieces can be fed out or stacked. The LOOPTEQ O-600 is best suited for customers with high material variety and a production with high automation degree.
תכונות ויתרונות
Low quality costs – gentle handling via vacuum traverse Flexible operator organization – thanks to economic one-man operation
Ergonomic working process – operator will be released from heavy physical work Intelligent automationinterlinked material flow with high capacity
- Efficiency increase – defined rotation for process optimized panel return
Features
- The LOOPTEQ O-600 perfectly harmonizes in size, capacity, and speed with HOMAG Group‘s unilateral edge banding machines
- Up to 2 destacking places are optional possible, depending on requirements
- High performance and an improved positioning accuracy thanks to a highly precise linear guideway
- Higher dynamics and a smoother running due to an electronically controlled z-axis
- Automatic turning of the parts (0°,+/- 90°, 180°)
- Stacking without pit, no lifting table, no hydraulics neccesary
- Simple belt cleaning equipment is already included in the standard
- Energy savings of up to 30% thanks to a new electric drive of the z-axis
סרטון
נתונים טכניים
| LOOPTEQ | O-600/30 | O-600/25 |
|---|---|---|
| אורך חלק | 240 - 3,000 | 240 - 2,500 |
| רוחב חלק | 80 - 1,200 | 80 - 1,200 |
| הדבקה 4 צדדים* מידות מינימום ממ | 240 × 120 | 240 × 120 |
| הדבקה 4 צדדים מידות מקסימום ממ | 3,000 × 1,200 | 2,500 × 1,200 |
| עובי חלק ממ | 8 - 60 | 8 - 60 |
| משקל חלק מצימום קג | 80 | 80 |
| מסה לשטח יחידת קג/מ | 25 | 25 |
| גובה עבודה ממ | 835 - 950 | 835 - 950 |
| Feed Speed [m/min] | 12 - 36 | 12 - 36 |
*Depending on the equipment of the processing machine; other workpiece dimensions on request .
